9-to-15 Pin Conversion Table
9 PIN SIGNALS PIN NO. 15 PIN SIGNALS PIN NO.
Red 1 Red 1
Green 2 Green 2
Blue 3 Blue 3
Horz Sync 4 Horz Sync 13
Vert Sync 5 Vert Sync 14
Red Ground 6 Return Red 6
Green Ground 7 Return Green 7
Blue Ground 8 Return Blue 8
Sync Ground 9 Digital Ground 10
Ground 5
Analog Video Signals
Black Level = 0 V
Full Intensity (White) Level = +0.7 V
Technical Support
In the event you have a technical problem with this product,
please read the README files in the software CD_ROM.
Updated drivers are available through Jaton Web site. Have
following information handy when you contact technical
support:
; Name of the product.
; Software Driver and Version.
; System Information, such as CPU speed, BIOS version, Monitor
Specification, etc.
; Description of the problems including any error messages.
Telephone:
(408) 934-9369 9-5 PST Mon. - Fri.
FAX:
(408) 942-6699
WEBsite:
www.jaton.com
34
