Jaton 3DForce2MX - Hardware Installation; Installation Procedures

Display devices connection: ( TVout)
Plate
TV set
PC Computer
DB 15 VGA
Connector
S_Video
Connector
RCA Composite
Connector
Hardware Installation
Installation Procedures
!! WARNING !!
Discharge static electricity by
touching the GROUND such
as metal part of your case
connected with good power
ground before you handle the
electronic circuit boards.
