J3 Back 106109
EU=Rev.4.0
6
ENGLISH
Sunrise Medical recommends that a clinician such as a
doctor or therapist experienced in seating and positioning be
consulted to determine if a J3 Back is appropriate.
WARNING!
Backs should only be installed by:
• an authorized Sunrise Medical supplier.
• a qualified and competent healthcare professional
who has undergone appropriate certified training by
either sunrise medical or their approved supplier.
THE JAY J3 BACK INTENDED USE
The Jay J3 Back is intended to provide a back support for
a wide variety of wheelchair users. It is designed to provide
simple, comfortable and effective support to help maximize
function and increase sitting tolerance. In addition, it is light-
weight, durable and easy to use.
The back can be installed onto a wide range of wheelchairs.
Maximum user weight:
300 lbs. (136 kg) – compact (and old standard hardware)
500 lbs. (227 kg) – heavy duty compact hardware
The intended lifetime of the back rest is 4 years.
WARNING
Installing a back support on a wheelchair may affect the
center of gravity of the wheelchair and may cause the
wheelchair to tip backwards potentially resulting in injury.
Always assess for the potential need for anti-tippers
or amputee axle adapter brackets to be added to the
wheelchair to help increase stability.
WARNING
Do not use J3 Back to push or lift wheelchair. Improper
use may cause the back to unexpectedly detach from the
wheelchair.
WARNING
Do not use the J3 back handle to lift wheelchair. It is
intended only for back removal.
WARNING
Carelessness causes fire.
WARNING
Please read this manual before usage.
J3 BACK
10mm
Spanner
Lower
Thoracic
Mid Thoracic
Upper
Thoracic
Shoulder
Height
SH
UT
MT
LT
Posterior
Posterior
Lateral
Posterior
Deep
Lateral
Posterior
Deep
Contour
Mid
Deep
Contour
Cover
Foam
Base
Shell
Locking Pin 4mm Hex Key
10mm
Spanner
INTRODUCTION
Compact
Hardware
HD Compact
Hardware
SC MC DC PDC MDC
