Rack mount Series UPS (1~3kVA) User ‘s Manual
-8-
shock.
2. DC port. One port is used for UPS DC input, another port is used for parallel battery pack.
3. Nut for connecting ground. Connect to ground when using.
4. Breaker
2.1.4 1~3kVA series rack mount and tower structure
1~3kVA series rack mount and tower structure please refer to following
drawing.
UPS rack mount structure
Battery cabinet rack mount structure
UPS tower structure Battery cabinet tower structure
Fig 2-6 1~3kVA UPS and battery cabinet rack mount and tower structure
