1.2 Performance Index
The main performance index of 1-3kVA Series is shown in Table 1-1.
Table 1-1 UPS Main Performance Index
Index Model 1kVA 2kVA 3kVA
Input Characteristic
Rating voltage (V) In range 160V~290V full load, 50% load even voltage low to 120V
Rating frequency (Hz) 50/60±5%
Input mode Single-phase three-line
Battery voltage (V)
36 72 96
Output Characteristic
Capacity (VA/W) 1000/700 2000/1400 3000/2100
Voltage (V) 220/230/240±2%
Frequency (Hz) 50/60±0.2％ (Battery mode)
Waveform Sine wave
Voltage distortion
factor
THD < 3% (Linear load)
Power factor 0.7 (Lag)
Switching time (ms) 0
Overload capacity 105%~130% Load, lasting 60 seconds. 135%~150% Load, lasting 30 seconds.≥150% lasting
300 milliseconds
Output mode Sockets Sockets
Other Characteristics
Backup time
5 minutes
(PC LOAD)
Rational
configuration
for long
backup type
5 minutes
(PC LOAD)
Rational
configuration
for long
backup type
5 minutes
(PC LOAD)
Rational
configuration
for long
backup type
Charge recovery time <12 hours (Standard time delay model)
Communication
interface
RS232(USB, relay dry connector and SNMP are optional)
Panel display LED or LCD displays operation status of UPS
Warning function Battery low voltage, abnormal power supply, UPS malfunction
Protection function Battery low voltage, overload, short-circuit and over temperature
Frequency noise (dB) < 45
Working temperature 0 ~ 40℃
Relative humidity 0 ~ 95%, No condensation
Size (mm)( W ×D×H) 440×460×88
Weight (kg) 14 7
UPS: 10
Battery pack:
22
12
UPS: 11
Battery pack:
28
13
◆ Specifications are subject to change without prior notice.
