To remove the tire from the tire carrier
1. Remove the lug nuts holding the tire in place.
2. Remove the support bracket from the bottom lug.
3. Pull the tire from the tire carrier.
Bumper mount
To install the tire on the tire carrier
1. Place the tire on the carrier with the top lug bolt inserted into one of the holes in the
tire rim and the bottom lug bolt in the center of the rim.
2. Install the top lug nut.
3. Place the support bracket over the bottom lug bolt across the center of the rim.
4. Install the bottom lug nut over the support bracket.
5. Make sure the lug nuts are tightened securely before returning to travel.
FIFTH WHEEL SET UP
1. Pull into the site, and park the RV where you want it.
2. Block the wheels securely to prevent the RV from moving.
3. Drop the landing gear (important!) Refer to the operator’s manual for proper
operation.
4. Disconnect the wire harness/connector plug and breakaway switch lanyard.
5. Drop the truck tailgate (unless you have a tailgate specially designed to accommodate
a fifth-wheel hitch).
6. Gently put your truck into reverse (don’t give it any fuel/acceleration).
This effectively moves the kingpin off the locking bar that will allow you to
disengage it.
7. Step on brake and apply parking brake.
8. Disengage the locking bar and unhitch.
9. Drive away.
10. Adjust the fifth-wheel height for proper front to back leveling of the RV.
PATIO AWNING
