SECTION 5-SLIDEOUT SYSTEMS JAYCO TOWABLE
Electric Slide Room System (If So Equipped)
The slideout room system is designed for additional floor space and comfort. The
mechanical components are gear driven. Electric powered slideout room systems have a
manual override to allow you to extend or retract the slideout room(s) in case of a power
loss. Make sure you have sufficient power available before operating your slideout system.
OPERATING THE SLIDEOUT
The Schwintek in-wall slideout system is designed to give you, the RV enthusiast, a
lifetime of trouble free service. It requires no maintenance it will never require any
adjustments.
The Schwintek in-wall system has two vertical columns, a left hand and a right hand. Each
of these columns has two serpentine gear racks that are attached to the slide room. Each
side has a drive motor located at the top of the column. The right hand and left hand
motors remain synchronized by the Dual Motor SynchronousVelocity Slide Controller (a
circuit board typically located in the basement area of the RV.
CAUTION
Do not place excessive weight in the slideout room. It can cause the slideout room to
malfunction and cause damage to the slideout.
WARNING
Make sure the interior slideout room path and the slideout room itself is clear of
people and objects before operating. Keep away from the slide rails and gear
assembly when the room is in motion. They may pinch or catch on loose clothing
causing personal injury. Failure to follow these instructions could result in serious
injury or death.
CAUTION
Make sure the vehicle is level before operating the slideout room. Water leaks and
other problems could result if the slideout is operated without leveling the vehicle.
CAUTION
Make sure the slideout is in the closed position prior to hooking the unit to the tow
vehicle.
CAUTION
Additional support jacks are not needed under the slideout. Damage can occur to your
slideout room from improper use of aftermarket support jacks.
5-1
