38
Air Conditioner (Option)
To meet State, National, and RVIA codes as well as support from manufacturer of
camper, you need to have installed a special kit to provide proper operation and energy
for successful enjoyment. To comply with all applicable codes, it must have the following:
1. 20-amp receptacle with 12 gauge wire.
2. 20-amp power cord to feed air conditioner.
3. Two twist caps.
The weight limit for air conditioners is 110 lbs. Exceeding this weight can damage the
roof and lifter system which will not be covered by your Jayco Limited Warranty.
DuoTherm and RVP brands usually are acceptable for folding camping trailer roof
installations. Other brands may be used if the weight is 110 lbs. or less and the interior
shroud fits around the roof components.
DuoTherm DuoTherm
BTU BriskAir Penguin Coleman
7,100 74 lbs. 88 lbs. 75 lbs. use #6727
11,000 92 lbs. 104 lbs. 92 lbs. use #6757 A, D, or E Series
13,500 96 lbs. 109 lbs. 95 lbs. use #6757 A, D, or E Series
WARNING: Any electrical installation that does not meet the criteria may
damage the electrical system and cause problems which will not be covered
under your Jayco Limited Warranty.
WARNING: Follow the wiring listed below as it attaches to the air
conditioner.
Outer Smooth Protective Covering = Positive Black
Outer Ribbed Protective Covering = Neutral White
Center Smooth Protective Covering = Ground Green
Failure to wire as specified will send reversed polarity in the air condi-
tioner, causing a potentially dangerous situation with the possibility of fire.
Follow the air conditioner installation instructions as supplied with the air conditioner.
Connect the 20-amp power cord to the air conditioner as listed above warning. Notch the
interior air conditioner shroud so the cord can pass between it and the roof. Using p-
clamp, secure the cord to the outer edge of ceiling and let it hang down the side of the
tent. It is code violation to run the 120-volt cord through a conduit of any type of
covering. The cord
must be visible.
