JAYCO TOWABLE SECTION 7 – FUEL & PROPANE SYSTEMS
7-5
LP gas container overfill
Never allow your propane tank to be filled above the maximum safe level as indicated by
the fixed liquid level gauge. Do not allow the visible gauge to be used for filling.
Overfilling the propane container above the liquid capacity indicated on the container,
could allow liquid propane to enter the system that is designed for vapor only creating a
hazardous condition.
The following label should be kept permanently affixed to your RV.
“Do not fill to more than
80%” label
(Label appearance may not be exact)
Refer to your Warranty Packet for more information on the LP gas system components.
INSTALLING PROPANE CYLINDER(S)
Single Cylinder Mounted On A-Frame (if so equipped)
Single cylinder
1. Connect the 3/8" low pressure hose to the outlet of the two stage regulator.
2. Attach the regulator with the “Z” bracket on the center of the front wall with the vent
pointing down.
3. Attach the protective plastic cover to the regulator.
4. The regulator has a 90° elbow that directs the inlet toward the trailer curbside.
5. Place the cylinder on the bracket provided on the A-frame and position it so the outlet
of the cylinder valve is pointed directly outward to the curbside wall.
WARNING
If you suspect your propane container has been overfilled, contact your independent
Jayco dealer or a qualified propane technician for assistance immediately. Do not
attempt to service a propane container overfill yourself.
