30
Your RV is equipped with chains to meet SAE standard requirements for maximum gross
trailer weight. Always have the safety chains attached when towing. Install them as shown
below so they do not restrict sharp turns, but tight enough so they do not drag on the ground.
Crisscross the left safety chain under the coupler and attach to the right mounting slot in the
trailer hitch; repeat with the right safety chain. Slack for each length should be the same but
not more than necessary to permit the vehicle to turn at its minimum radius, but tight enough
not to drag on the ground.
Wire Harness/Connector Plug
A 7-way wire harness/connector plug is wired into your trailer to connect electrical power
from the tow vehicle for travel. This supplies power to the RV brakes, taillights, clearance
lights, turn signals, brake lights, etc. Wiring to operate your brakes must be the same size in
both the tow vehicle and RV (the RV brake wiring is 12-gauge wire).
