51
Electric Slide Room(s) (if so equipped)
The mechanical components of the slide out are gear driven. Electric powered slideout room
systems have a manual override to allow you to extend or retract the slideout room(s) in case
of a power loss.
Slideout switches are typically located inside the RV, either in the command center or on the
wall. If your RV is equipped with a touch screen control system, your slide room controls
will be built into the touch screen system.
and con-
nected. I
The RV must be level and the .
, locate the slideout control switch and press the OUT
section of the switch; hold until the slideout room stops (travel time is approx. 25
seconds).
To retract the slideout, press the in section of the slideout control switch and hold
it until the slideout is fully retracted.
Operating the switch after the room is fully extended or retracted may damage the switch
and motor.
These guidelines should be followed when using your slideout room:
Make sure the slideout is in the closed position prior to hooking the unit
to the tow vehicle.
The recreation vehicle before operating the slideout room.
Water leaks and other problems could result if the slideout is operated
without leveling the RV.
in the slideout room. It can cause the
slideout room to malfunction and cause damage to the slideout.
Do not over extend/retract the slide out room. Release the switch imme-
diately once the room has been fully extended/retracted. Over extending/
retracting the slide out room may result in damage to the stop rod and
bracket.
Additional support jacks are not needed under the slideout. Damage can
occur to your slideout room from improper use of aftermarket support
jacks.
Make sure the interior slideout room path and the slideout room itself is
clear of people and objects before operating.
Keep away from the slide rails and gear assembly when the room is in
motion. They may pinch or catch on loose clothing causing personal
injury.
