52
After the slideout is extended, visually inspect the slideout and the
surrounding area to make sure the slideout has extended properly and
has adequate clearance from any outside obstructions.
If the slideout is equipped with rubber seals, verify that the corners of
the black rubber seal are set up correctly. The seal corners are cut at
a 45° angle. The top of the outside seal must overlap the side of the
seal to avoid the possibility of water penetration. On the inside seal,
the side seal should overlap the top.
Check the auxiliary battery (customer supplied) for a full charge and good wire
connections.
Check the 12-volt fuse or circuit breaker.
Check for loose connections at the slideout motor.
If the slideout is extended, refer to the section on operating the specic slideout
system installed on your RV.
If the slideout is retracted, leave it in that position.
Follow steps on overriding the specic slideout system installed on your RV.
You may need to push the side that is not sliding to get it to retract all the way.
Contact your dealer or customer service for repair assistance.
Your RV may be equipped with one or more of the following slideout
systems.
For optimum performance, the slideout system requires full battery current and voltage.
Although the system is almost maintenance free, actuate the room once or twice a month to
keep the seals and internal moving parts lubricated.
refer to the general troubleshooting checklist
before proceeding.
1. Level the unit.
2. Main Power switch at stepwell (locations may vary) must be ON.
3. Verify the battery is fully charged and hooked up to the electrical system.
4. Remove the transit bars (if so equipped) if extending the slideout, and install them if
retracting the room for travel.
5. Press and hold the IN/OUT switch in the OUT position until the room is fully extended
