53
and stops moving. Hold the switch in the IN position to retract the room.
6. Release the switch, which will lock the room into position. If the slideout switch is held
after the room is fully extended or retracted, the control will sense that the room has
stopped and will shut the motor o after a few seconds.
Locate the crank extension under the inside of the frame (). Attach a standard
fth wheel landing gear crank handle, a ¾” socket and ratchet, or drill and nut driver.
Rotate the extension clockwise to retract the slideout and counterclockwise to extend it.
attempt to disengage the motor as the actuator is “manual ready”.
The in-wall slideout system requires no maintenance or adjustments. This system has two
vertical columns with a drive motor located at the top of each column. The right and left
motors are synchronized by a circuit board.
Always disconnect battery from system prior to manually operating
system. Failure to disconnect battery can cause electricity to back feed
through the motor and cause serious damage to the system as well as void
the warranty.
. The gears can be stripped out if the
room is manually retracted/extended to its fullest extent and the operator
continues to rotate manual override. Damage can also occur to the slide
components, slide room structure or trim components. Damages due to
misuse of the manual override feature will void any and all claims to the
Limited Warranty.
