7. Attach the 1/4" inverted flare x 24" Type 1 pigtail hose to the regulator inlet and the
right hand swivel nut to the cylinder valve.
8. If applicable, close the cylinder cover zipper up to the hose.
9. Secure the cylinder to the A-frame bracket using the bolts, nuts and washers
provided.
Main Supply Hose
The main supply hose will be attached from regulator to brass manifold fitting in frame of
camping trailer. Swivel brass nut on main hose will be your final attachment. There are
several things to remember each time the container is removed:
1. Check that ALL fittings are tight.
2. Ensure that ALL connections are tested with leak solution.
3. Open main valve slowly to avoid fast rush of gas to excess flow valve causing gas
freeze up. Should you experience a gas “freeze-up,” close main valve and wait fifteen
minutes before trying again.
4. Listen carefully - a “hissing” sound longer than one second may indicate a gas leak.
Close valve and search for leak.
ALL GAS LINES HAVE BEEN
CHECKED WITH AIR PRESSURE. DEAL-
ERS ARE REQUIRED TO
RECHECK AND ADJUST PRESSURE
BEFORE DELIVERY TO CUSTOMERS.
3/8" MPT x 1/2" Female
Flare Swivel
Fig. 4-6
41
