65
but there is no real interruption of power.
The ATS will disconnect from shore power completely if the power coming in is not high
enough quality (i.e. either low/high voltage, or low/high frequency).
When the generator is operating, it powers the inverter/charger which in turn functions as a
multi-stage battery charger to charge the house auxiliary and chassis batteries.
Refer to and follow safety information found in the manufacturer’s troubleshooting guide
found in your warranty packet.
120-Volt Circuit Breakers
The 120-volt AC circuit breakers located inside the load center protect all 120-volt wiring
and components from circuit overloads and short circuits. Should a circuit overload or short
circuit occur the circuit breaker protecting the aected circuit will “trip” preventing the ow
of electricity through that circuit.
If a circuit breaker trips, shut o the appliance on that circuit (i.e., power converter, etc.)
and allow the circuit breaker to cool down for a brief period of time. After it cools down,
reset the circuit breaker by moving its lever “o” and then back to the “on” position. If the
circuit breaker re-trips or frequently trips, contact your dealer to have the electrical problem
diagnosed and repaired.
A circuit breaker identication label is permanently attached to the inside surface of the 120-
volt Load Center.
Only replace circuit breakers with those of the same specied type, voltage, and current rat-
ing. Please
contact your dealer for repair assistance when replacing circuit breakers.
At the beginning of the camping season, inspect the circuit breakers and replace as needed.
Test by turning each circuit breaker “o” and back “on”. Circuit breakers are wearable parts
and must be replaced as needed as part of your RV maintenance. If you have any questions,
contact your dealer.
A label is provided to explain the function of every 120-volt circuit breaker. This label is
located on or near the appropriate load center or sub-panel and must remain permanently
axed to the recreation vehicle.
Circuit breakers and fuses will not oer complete protection of the electrical
system in the event of power surge or voltage spike.
Replacement circuit breakers must be of the same voltage, amperage rating
and type. Never use a higher rated replacement circuit breaker; doing so may
cause a re by overheating the RV wiring.
