A label is provided to explain the function of every 120-volt circuit breaker. This label is
located on or near the appropriate load center or sub-panel and must remain permanently
axed to the recreation vehicle.
Approximate Electrical Load Ratings
12 VOLT SYSTEM
Fan 1.5 AMPS
Furnace 12.0 AMPS
Illuminated Switch .125 AMP
Inverter variable
Light; LED 1.7 AMPS
Light; Vanity 4.2 AMPS
Lights; Aisle 1.0 AMP
Lights; Decorative Wall / Map / Porch 1.5 AMPS
Lights; Double -12” 2.0 AMPS
Lights; Double -18” 2.5 AMPS
Power Awning 10.0 AMPS*
Power Vent 5.0 AMPS
Refrigerator 3.0 AMPS
Water Pump 7.0 AMPS
*Momentary Load
12 Volts: Labeled watts divided by 12 = Power consumed in AMPS
120 VOLT SYSTEM
Air Conditioner 18 AMPS
Coee Maker 6-12 AMPS
DVD System 3 AMPS
Hair Dryer or Curling Iron 10-14 AMPS
Vacuum Cleaner 8 AMPS
120 Volts: Labeled watts divided by 120=Power consumed in AMPS
120-Volt, 30-amp AC Electric System
The 30-amp 120-volt 60hz AC electrical system is designed to operate on 1 leg of 120-volt
power at a maximum current ow of 30-amperes.
Exposure to voltages higher or lower than a nominal 120-volts will damage or shorten the
service life of the electrical system and appliances. The 30-amp 120-volt 60hz AC electrical
system can be powered by the 120-volt 60hz utilities found in campgrounds.
