OPERATION MANUAL
Thank you for buying this JB Systems
®
product. To take full advantage of all possibilities and for your own
safety, please read these operating instructions very carefully before you start using this unit.
FEATURES
• 3in1 LED Moving Head – Beam/Spot/Wash
• Ideal for rental companies, DJ’s, stage,…
• Based on a 150W high power LED
• Focus controlled by DMX
• Zoom controlled by DMX
• 3 facet rotating prism
• 0-100% dimming and different strobe effects
• Separate gobo wheel with 7 fixed gobos + open
• Separate gobo wheel with 6 rotating gobo’s + open
• Excellent built-in programs for wonderful, ever changing, light shows.
• Multiple working modes:
• DMX-control: via 5, 17 or 20 channels
• Standalone: sound activated with internal mic
• Master/slave:
• Wonderful synchronized shows in standalone mode
• Innovative 5CH SMART-DMX
• Prepared for wireless DMX: just plug-in an optional WTR-DMX DONGLE ! (Briteq
®
order code: B04645)
• Color LCD-display for easy menu navigation
• 3p and 5p XLR connectors for DMX in- and output.
BEFORE USE
• Before you start using this unit, please check if there’s no transportation damage. Should there be any, do
not use the device and consult your dealer first.
• Important: This device left our factory in perfect condition and well packaged. It is absolutely necessary
for the user to strictly follow the safety instructions and warnings in this user manual. Any damage caused
by mishandling is not subject to warranty. The dealer will not accept responsibility for any resulting defects
or problems caused by disregarding this user manual.
• Keep this booklet in a safe place for future consultation. If you sell the fixture, be sure to add this user
manual.
Check the contents:
Check that the carton contains the following items:
• [CHALLENGER BSW] unit
• 2 Omega-brackets
• ProCon-power cable
• Operating instructions
