8. M-DMX INPUT: Please note that this USB-connector is NOT used for updates or to connect the unit to a
PC! Instead this USB-connector makes it very easy to add wireless DMX to the unit! Just add the
(optional) WTR-DMX DONGLE from BRITEQ
®
and you will get wireless DMX! Moreover you will be able
to connect other DMX-controlled equipment to the DMX-output so you can share the wireless DMX
function with all connected units! No extra settings to be made in the setup menu, just follow the
procedure in the user manual supplied with the WTR-DMX DONGLE from BRITEQ
®
. The separate
WTR-DMX DONGLE is available from WWW.BRITEQ-LIGHTING.COM (order code: B04645)
9. [POWER IN]: Connect the mains input cable here.
10. FUSE HOLDER
SETUP MENU:
• This is the list of all the functions in the machine.
• To select any of these functions, press the [MENU] button and use the [▲/▼] buttons to browse the menu.
• Select the desired function with the [ENTER] button.
• Use [▲/▼] buttons to change the mode or value.
• Once the required mode or value is selected, press the [ENTER] button to select.
