ENGLISH USER MANUAL
JB SYSTEMS
®
11/16 COB-4BAR
Modes & Functions :
Press the MODE pedal to select the different working modes.
 COLOR Mode (Red LED is lit): in this mode you can select different static colors
 UP & DOWN pedals: can be used to select one of the different static colors.
 BLACKOUT pedal: press this pedal shortly to put the bar in blackout (the red, the green and the
yellow LEDs on the pedal board are lit). If you press this pedal for about 3 seconds, the bar will go
in Full On mode (all the projectors at full power in white color)
 SOUND Mode (Green LED is lit): in this mode you can select different sound controlled chases (don’t
forget to set the sensitivity of the build-in microphone via the rotary knob on the pedal board)
 UP & DOWN pedals: can be used to select one of the different sound modes.
 BLACKOUT pedal: press this pedal shortly to put the bar in blackout (the red, the green and the
yellow LEDs on the pedal board are lit). If you press this pedal for about 3 seconds, the bar will
return to COLOR Mode in Full On mode (all the projectors at full power in white color)
 SOUND Mode (Yellow LED is lit): in this mode you can select different automatic chase modes
 UP & DOWN pedals: can be used to select one of the different automatic chase modes.
 BLACKOUT pedal: press this pedal shortly to put the bar in blackout (the red, the green and the
yellow LEDs on the pedal board are lit). If you press this pedal for about 3 seconds, the bar will
return to COLOR Mode in Full On mode (all the projectors at full power in white color)
Extra Function:
The UP & DOWN pedals can also be used to switch on/off the 2 power outputs for the additional
fixtures. Press the UP pedal for about 3 seconds to switch on/off power output 1. Press the DOWN
pedal for about 3 seconds to switch on/off power output 2.
G. Controlled by a universal DMX-controller:
 Connect all units together. Refer to the chapter “Electrical installation for two or more units in DMX-
mode” to learn how to do this (don’t forget to address all units properly!)
 Connect all units to the mains and turn on the DMX controller.
Since each unit has its own DMX-address, you can control them individually. Remember that each unit
uses 3, 5, 6, 8, 12, 16, 17 or 18 DMX Channels, depending on the DMX-mode you have selected in the
menu. See the different DMX charts below:
DMX Chart for the 3 channel DMX-Mode
Channel:
Name
Value:
Function:
1
Red
000-255
Dimmer (0-100%)
2
Green
000-255
Dimmer (0-100%)
3
Blue
000-255
Dimmer (0-100%)
DMX Chart for the 5 channel DMX-Mode
Channel:
Name
Value:
Function:
1
Red
000-255
Dimmer (0-100%)
2
Green
000-255
Dimmer (0-100%)
3
Blue
000-255
Dimmer (0-100%)
4
Extra Power output 1
000-127
Power OFF
128-255
Power ON
5
Extra Power output 2
000-127
Power OFF
128-255
Power ON
DMX Chart for the 6 channel DMX-Mode
Channel:
Name
Value:
Function:
1
Red 1
000-255
Dimmer Projector 1 & 2 (0-100%)
2
Green 1
000-255
Dimmer Projector 1 & 2 (0-100%)
3
Blue 1
000-255
Dimmer Projector 1 & 2 (0-100%)
4
Red 2
000-255
Dimmer Projector 3 & 4 (0-100%)
5
Green 2
000-255
Dimmer Projector 3 & 4 (0-100%)
6
Blue 2
000-255
Dimmer Projector 3 & 4 (0-100%)
