FEATURES & SPECIFICATIONS
Ø Operating in UHF band frequency with synthesizer controlled.
Ø The wireless microphone system with 16 selectable frequencies via Phase Locked Loop
(PLL) circuitry makes it easy to choose non-interfered channels.
Ø Diversity with two antennas to ensure the reception quality.
Ø Super high sensitivity, extremely low noise transmission and reception.
Ø SMT assembled PCB module ensures the quality and stability.
10. System Specification
Receiver
Ø Carrier Frequency Range : UHF band
Ø Frequency Stability : ±0.005%
Ø S/N ratio : > 94dB, at 48KHz deviation and 60dBmV antenna input
Ø Maximum Deviation : ±48KHz
Ø Image and Spurious Rejection
: 80 dB minimum
Ø Receiving Sensitivity
: 8 dBμ V.
Ø Selectivity : > 50dB
Ø AF Response
: 50Hz to 15KHz (±3dB)
Ø T.H.D. : < 1% (at 1KHz)
Ø Audio Output : Balanced and unbalanced audio outputs
Ø Current consumption : 500mA ±10mA
Ø Power Supply : 12V DC
Ø Dimensions : 420(W) x 180(D) X 45(H) mm
Handheld/Bodypack Transmitter
Ø Carrier Frequency Range : UHF band
Ø RF Power Output : 10mW (max.)
Ø Oscillation Mode : PLL synthesized
Ø Frequency Stability
: ±0.005%
Ø Maximum Deviation
: ±48KHz
Ø Spurious Emission : More than 60dB below carrier frequency
Ø T.H.D. : Less than 1% (at 1KHz)
Ø Microphone Capsule
: Handheld: uni-directional dynamic or uni-directional electret
condenser unit
Lavalier: uni-directional electret condenser unit
Ø Operating voltage : DC1.5V x 2 AA size batteries
Ø Current consumption
: 65mA ± 5mA
Ø Dimension (mm)
: UF-16A: 56j x263mm;UT-16A:64(W)x97(H)x24(D)
DESIGN AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
