5.2 Handheld Microphone
The handheld microphone operates in UHF band frequency with PLL synthesized control. UHF
16 preprogrammed selectable frequencies to avoid interference. Uni-directional dynamic or
uni-directional condenser capsules with different characters for various choices. Use 1.5V x 2
AA size batteries for low operating cost.
1. Grille: Protects the microphone capsule and helps reduce breath sounds and wind noise.
The grille for the various microphone capsules differ in appearance.
2. Low Battery LED: LED indicates battery life status. Switching the power to "ON", the
LED flashing once indicates that the transmitter has sufficient power. If the LED stayed on,
it indicates that the battery has insufficient power and should be changed soon. If the status
LED fails to flash, the battery is either dead or not positioned correctly, and you should
correct the positioning or change the battery.
3. On/off Switch: Turns transmitter power on and off.
4. Battery Compartment: Insert two AAA batteries into the compartment and make sure that
the polarity of batteries is correct.
5. Channel Selector: Changes transmitter Channel setting.
6. Battery Cover: Push to expose battery compartment and Group/Channel selector.
7. Antenna: Built-in high gain helical antenna.
