jbc CD-BQF - Operation

0
c
Power 5%
Power 5%
350
Selected temp
350
350
o
o
C
C
Sleep temp 150
Sleep temp 150
o
o
C
C
Sleep
0
c
35 0
Tool in the stand, no heat
Hibernation
0
c
35 0
OK
TOOL
EARTHING FUSE
AUX
USE ONLY WITH A 250 V FUSE
OK
TOOL
EARTHING FUSE
AUX
USE ONLY WITH A 250 V FUSE
OK
TOOL
EARTHING FUSE
AUX
USE ONLY WITH A 250 V FUSE
Operation
The JBC Most Efficient Soldering System
This revolutionary technology is able to recover tip temperature extremely quickly.
This allows the user to work at a lower temperature.
As a result, tip life increases by 5.
· Change temperature
(from 90 to 450ºC)
Steps ± 5
Steps ± 50
Through menu settings:
· Select temperature levels
· Fix one temperature
Through menu settings:
· Change Sleep temperature
· Set Sleep delay
(from 0 to 9 min or no Sleep)
Through menu settings:
· Change Hibernation delay
(from 0 to 35 min)
Long time in
the stand
1. Work 2. Sleep 3. Hibernation
When the tool is lifted from the
stand the tip will heat up to the
selected temperature.
When the tool is in the stand,
the temperature falls to the
preset sleep temperature.
After longer periods of
inactivity, the power is cut off
and the tool cools down to
room temperature.
8
