jbc HD Series User Manual

7
Main menu
Counters
Tool settings
Exit
1 Reset settings
2 Station settings
3 Tool settings
1 Plugged hours 0
2 Working hours 0
3 Sleep hours 0
1 Fix one temp -----
2 Temp levels set OFF
3 Sleep delay 0 min
4 Counters
5 Program version
4 Hibernation hours 0
5 No tool hours 0
6 Sleep cycles 0
4 Sleep temp 180
0
C
5 Hibernation delay 3 0 min
6 Temp adjust + O
O
C
Tool 245
Tool 245
Back
Back
0
c
Selected temp. 350
o
C
Po wer 10 %
350
Decrease & move down Increase & move up
Tip temperature
% Instant power supplied to the tool
ORIGINAL PIN: 0105
Station settings
1 Temp unit Celsius
2 Maximum temp 400
0
C
3 Minimum temp 200
0
C
4 Help text OFF
5 Beep ON
6 Power limit 250W
7 Change PIN
Back
Access Menu
&
Confirm
Selection
CONTROL SCREEN
SETTINGS MENU
