Tilt Guide for 2 x 2 Array -
(Suspended from holes 3 - C, connecting shackle mounts towards rear)
The top tier of this array can be aimed directly horizontal, while the lower tier can have an aim angle of -28” for a
vertical coverage angle of 64”. This array could be very useful for applications requiring balcony coverage and
down fill.
.
Tilt angles for selected holes
Direction of Shackle
Location of Shackle
Mount on Truss
Mount on top Array
Table 1
