JBL ATX10C - Specifications

JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
Europe: 2. Route de Tours, 72500 Château du Loir, France
www.jbl.com
©2002 JBL, Incorporated.
JBL is a registered trademark of JBL, Incorporated.
Part No.
1111-ATXSERIES
Refinements may be made on occasion to existing products without notice, but will always meet or exceed original specifications unless
otherwise stated.
*Dolby and Pro Logic are trademarks of Dolby Laboratories. DTS
®
is a registered trademark of Digital Theater Systems, Inc.
ATX 20 30 40
Type: 2-way 3-way 3-way
Frequency Response: 75Hz–20kHz 55Hz–20kHz 55Hz–20kHz
Sensitivity (2.83V/1m): 86dB 88dB 89dB
Nominal Impedance: 6 Ohms 6 Ohms 6 Ohms
Power Handling Peak/Continuous: 100/60 Watts RMS 150/100 Watts RMS 200/160 Watts RMS
Recommended Amplifier Power*: 20 – 60 Watts 20 - 80 Watts 30 - 120 Watts
RMS per Channel RMS per Channel RMS per Channel
Crossover Frequency: 4000Hz 800/3500Hz 800/3500Hz
Connection: Single wired with 5-way Single wired with 5-way Single wired with 5-way
binding posts binding posts binding posts
High Frequency Driver: 10mm Titanium Laminate 10mm Titanium Laminate 10mm Titanium Laminate
Dome tweeter Dome tweeter Dome tweeter
Midrange Frequency Driver: - 100mm Laminated 100mm Laminated
- Paper Cone Paper Cone
Low Frequency Driver: 165mm Laminated 165mm Laminated Two 165mm Laminated
Paper Cone Paper Cone Paper Cones
Finish: Black Ash or Beech Vinyl Laminate with Dark Grey Grille
Dimensions (H x W x D): 350 x 202 x 237mm 865 x 202 x 286mm 865 x 202 x 286mm
Weight (per piece): 5kg 13.5kg 14.5kg
ATX 60 10C Center 100S Subwoofer
Type: 3-way 2-way Active Subwoofer
Frequency Response: 50Hz–20kHz 80Hz–20kHz 45Hz–150Hz
Sensitivity (2.83V/1m): 89dB 86dB -
Nominal Impedance: 6 Ohms 6 Ohms -
Power Handling Peak/Continuous: 200/160 Watts RMS 100/60 Watts RMS -
Recommended Amplifier Power*: 40 – 120 Watts 20 – 60 Watts 100 Watts
RMS per Channel RMS per Channel RMS (1% THD)
Crossover Frequency: 800/3500Hz 3500Hz -
Connection: Single wired with 5-way Single wired with 5-way 5-way binding posts
binding posts binding posts Stereo in (RCA Phono)
LFE in (RCA Phono)
High Frequency Driver: 10mm Titanium Laminate 10mm Titanium Laminate -
Dome tweeter Dome tweeter
Midrange Frequency Driver: 100mm Laminated - -
Paper Cone -
Low Frequency Driver: 250mm Laminated Two 100mm Laminated Paper 200mm Laminated
Paper Cone Cones, Magnetically Shielded Paper Cone
Finish: Black Ash or Beech Vinyl Laminate with Dark Grey Grille
Dimensions (H x W x D): 950 x 286 x 315mm 158 x 410 x131mm 350 x 295 x 350mm
Weight (per piece): 20kg 3kg 13kg
*Recommended Amplifier range is provided as a guideline only. Use of underpowered amplifiers may result in damage to the loudspeakers.
ATX20/30/40/60/10C/100S (230V)
ATX Series
OWNER’S GUIDE
PRODUCT LINE:
DESIGN GOAL: Bring the thrill of live performance and movie sound to the
home environment by calling on JBL’s professional engineering leadership.
PROFESSIONAL REFERENCE: Home Loudspeaker Series
MODEL
NUMBER:
PRO SOUND
COMES HOME
™
SPECIFICATIONS
