Need help?Do you have a question about the JBL CS300.1 and is the answer not in the manual?
Power| power at 4 ohms | 200W RMS x 1 channel |
|---|---|
| power at 2 ohms | 300W RMS x 1 channel |
| dynamic power at 2 ohms | 460W |
Audio Performance| signal-to-noise ratio | 100dBA |
|---|---|
| frequency response | 10Hz – 300Hz |
| effective damping factor | 6.395 at 4 ohms |
Input and Output| maximum input signal | 6V |
|---|---|
| maximum sensitivity | 100mV |
| output regulation | –0.07dB at 4 ohms |
Weight and Dimensions| dimensions (L x W x H) | 12-11/16" x 10-1/4" x 2-3/16" |
|---|---|
| fuses | 20A x 2 |
Power| power at 4 ohms | 60W RMS x 4 channels |
|---|---|
| power at 2 ohms | 80W RMS x 4 channels |
| dynamic power at 2 ohms | 145W |
Audio Performance| signal-to-noise ratio | 86dBA |
|---|---|
| frequency response | 10Hz – 27kHz |
| effective damping factor | 6.395 at 4 ohms |
Input and Output| maximum input signal | 6V |
|---|---|
| maximum sensitivity | 100mV |
| output regulation | –0.03dB at 4 ohms |
Weight and Dimensions| dimensions (L x W x H) | 13-1/4" x 10-1/4" x 2-3/16" |
|---|---|
| fuses | 25A x 2 |
Power| power at 4 ohms | 60W RMS x 2 channels |
|---|---|
| power at 2 ohms | 80W RMS x 2 channels |
| dynamic power at 2 ohms | 160W |
Audio Performance| signal-to-noise ratio | 86dBA |
|---|---|
| frequency response | 10Hz – 27kHz |
| effective damping factor | 6.395 at 4 ohms |
Input and Output| maximum input signal | 6V |
|---|---|
| maximum sensitivity | 100mV |
| output regulation | –0.03dB at 4 ohms |
Weight and Dimensions| dimensions (L x W x H) | 8-7/8" x 10-1/4" x 2-1/4" |
|---|---|
| fuses | 25A x 1 |
