Installation Point Qty. Description Material No.
1 MAIN PCB ASSY HI APE200061-4001
IC302 1 IC 14 PIN TL074CD RCI000740-0001
IC621 IC622 IC623 IC701 4 IC 8 PIN TL072CD RCI000720-0001
IC620 1 IC 42 PIN M62446FP MITSUBISHI RCI062446-0001
IC301 1 IC 16 PIN TC4052BFN CHIP RCI004052-0001
IC201 1 IC 44 PIN TC9819 U-CON V2 MASK RCI870047-0082
Q101 Q102 Q103 Q104 Q301 Q302 Q505 7 XISTR NPN SMT (2SC945) RCN200945-0001
Q506 1 XISTR PNP 2SA812 hfe:200~400 RCP200733-0001
ZD601 ZD602 2 DIODE ZENR 6.9-7.2V 0.5W RAZ005007-0020
D201 D202 D203 D303 11 CHIP DIODE LL4148 TELEFUNKEN RCD104148-0010
D304 D305 D306 D307 D308 D601 D208
D650 1 DIODE;RECTIFIER 1N4002 RAD114001-0010
ZD301 1 DIODE ZENR 2.3-2.5V 0.5W RAZ005002-0020
ZD201 1 DIODE ZENR 5.6-5.9V 0.5W RAZ005006-0020
R832 JP01 R738 3 CHIP RES. 0 OHM JUMP WIRE QCF015020-0000
R383 R384 2 CHIP RES. 10 OHM 1/10W 5% QCF015020-1000
R880 R317 R318 R835 9 CHIP RES. 100 OHM 1/10W 5% QCF015020-1010
R876 R877 R878 R879 R881
R309 R310 R313 R314 14 CHIP RES. 1K OHM 1/10W 5% QCF015020-1020
R331 R373 R374 R846
R864 R865 R868 R869 R875 R336
R101 R103 R106 R108 23 CHIP RES. 10K OHM 1/10W 5% QCF015020-1030
R113 R214 R311 R312
R319 R320 R325 R326
R330 R333 R335 R337
R529 R542 R821 R101A R118 R119 R120
R380 R527 2 CHIP RES. 100K OHM 1/10W 5% QCF015020-1040
R107 R321 R322 R378 R379 5 CHIP RES. 1M OHM 1/10W 5% QCF015020-1050
R104 R109 R110 R327 R327A 5 CHIP RES. 150 OHM 1/10W 5% QCF015020-1510
R211 1 CHIP RES. 1.8K OHM 1/10W 5% QCF015020-1820
R833 R834 2 CHIP RES. 2.4K OHM 1/10W 5% QCF015020-2420
R332 1 CHIP RES. 22K OHM 1/10W 5% QCF015020-2230
R329 R334 R801 R803 R804 R805 R816 8 CHIP RES. 220K OHM 1/10W 5% QCF015020-2240
R802
R301 R302 R303 R304 9 CHIP RES. 24K OHM 1/10W 5% QCF015020-2430
R305 R306 R307 R308 R377
R862 R863 R866 R867 R873 R874 6 CHIP RES. 2.7K OHM 1/10W 5% QCF015020-2720
R210 R315 R316 3 CHIP RES. 3.3K OHM 1/10W 5% QCF015020-3320
R817 R818 R819 R828 R829 5 CHIP RES 3.6K OHM 1/10W 5% QCF015020-3620
R381 R382 2 CHIP RES. 470 OHM 1/10W 5% QCF015020-4710
R212 R213 R226 R236 15 CHIP RES. 4.7K OHM 1/10W 5% QCF015020-4720
R323 R324 R215 R216 R217 R218 R220
R221 R223 R224 R219
R105 R112 R225 R526 R528 5 CHIP RES. 47K OHM 1/10W 5% QCF015020-4730
R885 R886 2 RESISTOR 150 OHM 1W 5% MF HI QHM105000-1510
R375 R376 2 CHIP RES. 680 OHM 1/10W 5% QCF015020-6810
R830 R822 R827 R836 R837 R842 R843 9 CHIP RES. 8.2K OHM 1/10W 5% QCF015020-8220
R844 R845
R102 1 CHIP RES. 5.1K OHM 1/10W 5% QCF015020-5120
R372 1 RESISTOR 4.7K OHM 1/6W 5% CF QAF065000-4720
R810 R811 R812 3 RESISTOR 22K OHM 1/6W 5% CF QAF065000-2230
L301 1 CHOKE 10 uH 10% SAN001600-1000
R232 1 RESISTOR 100 OHM 1/6W 5% CF QAF065000-1010
C202 C203 2 CHIP CAP 18 pF 50V 5% PYL410370-1800
C317 C318 2 CHIP CAP 22 pF 50V 5% PYL410370-2200
C303 C304 C309 C310 18 CHIP CAP 47 pF 50V 5% PYL410370-4700
C328 C331 C363 C364
C769 C773 C777 C780
C781 C782 C358 C359 C360 C361
C301 C302 C307 C308 4 CHIP CAP 100 pF 50V 5% PYL410370-1010
C102 C106 C110 C111 13 CHIP CAP 0.1 uF 50V 5% PYL456370-1040
C206 C211 C325 C326 C703 C704 C321A
C322A C110A
C101 C105 2 CHIP CAP 0.01 uF 50V 5% PYL456370-1030
C208 C362 2 CHIP CAP 0.022 uF 50V 5% PYL456370-2230
C702A C752 C753 C755 11 COND ELECT 47uF 10V 20% PRE039530-4700
C766 C767 C783 C784 C786 C787 C788
C207 1 COND ELECT 47uF 16V 20% PRE039540-4700
