JBL ESC 360 - ESC360 Parts List

ITEM PART NUMBER MATERIAL DESCRIPTION
1 EVM200002-0001 WOOD BOX W300xH300xD300mm
2 BPR000020-0001 PORT EDGE ABS W/SPRAY MA4810
3 BPR000042-0BA0 PORT (F) ABS MA4810
4 BPF005056-0AY1 CNTL PANEL METALIC LIGHT GREY SILVER
5 BFP211001-0001 PVC PLATE
6 BPL000013-0001 LOGO PLATE 22.5xW18mm JBL
7 BPK005031-0000 CONTROL KNOB W/SPRAY MA4810
8 APE200140-4001 CNTL PCB ASSY (HI)
9 IVE200001-0001 SPONGE OD165xID143xT1.0mm
10 FSA226061-1401 SPK DRIVER 6.5" 4OHM 60W
11 BPE000005-0002 FOOT D25xL25 LIGHT GREY W/MA4810 SPRAY
12 BRF200001-0001 RUBBER FOOT NR3 BLACK 13.5xT2.0mm W/ADHE
13 IVE200002-0001 SPONGE L268xW268xT2.0mm
14 APE200065-4001 LED INTERFACE PCB ASSY HI
15 GSE200008-0001 REAR PANEL SECC T=2.0mm CEDCOATTING BLK
16 ICH209001-0001 SPONGE FIBER T0.5mm 268x120mm
17 GAL200004-0001 HEAT SINK L AL W/ANODIZING BLK
18 APE200063-5001 DC PCB ASSY CHASSIS
19 GSE200010-0001 PCB BKT R SECC T=1.0mm
20 GSE200011-0001 PCB BKT L SECC T=1.0mm
21 CFC021001-1001 FUSE HOLDR FUSE HOLDER FH-B02
22 BRB200001-0001 RUBBER BUSHING BLACK W/UL
23
DBU001002-0011 BUSHING AC LINE BUSHING HEAVY POWER 4K-4
24 MSW008004-0010 SW ROCKER 5A AC 250V TV-5
25 TTK223001-0001 PWR TRANS EI-96 230V
26 APE200064-5001 SPK JACK ASSY CHASSIS
27 IVE200010-0001 SPONGE A EVA
28 APE004710-4004 DECODER PCB ASSY AC3 DTS/DSP HI
29 GSE200020-0001 PCB BKT L SECC T=1.0mm
30 GSE200021-0001 PCB BKT R SECC T=1.0mm
31 BPC200001-0001 PCB COVER A ABS LIGHT GREY
32 IVE200004-0001 SPONGE B EVA
33 IVE200003-0001 SPONGE A EVA
34 APE200061-5001 MAIN PCB ASSY CHASSIS
35 BPC210001-0001 PCB COVER B ABS LIGHT GREY
36 GAL200003-0001 HEAT SINK AL W238xH32mm W/ANODIZING BLK
37 GSE200009-0001 PCB BKT L T=1.0mm
38 APE200062-5001 AMP. PCB ASSY CHASSIS
39 GSE200012-0001 PCB BKT Z SECC T=1.0mm
S1 HSP140054-3080 SCREW T3.0xL8xP1.06mm BLACK OXIDE
S2 HST140054-3100 SCREW T3.0xL10xP1.06mm BLACK OXIDE
S3 HSD143103-3200 SCREW M4.0xP0.7xL20 mm C
S4 HSP143083-3140 SCREW ;M3.0xP0.5xL14mm PAN HEAD BLAC
K
S5 HST140051-3220 SCREW T3xL22xP1.06mm BLACK OXIDE
S6 HSP140091-3200 SCREW T4xL20xP1.59mm BLACK OXIDE
S7 HST140054-3060 SCREW T3xL6xP1.06mm BLACK OXIDE
S8 HSP140074-3080 SCREW T3.5xL8xP1.41mm BLACK OXIDE
S9 HSP140054-3100 SCREW T3.0xL10xP1.06mm BLACK OXIDE
S10 HSP140091-3160 SCREW T4.0x1.59PxL16mm BLACK PAN HEAD
S11 HST140071-3140 SCREW T3.5xP1.41x14mm BLACK OXIDE
S12 HSP140054-3060 SCREW T3.0xL6xP1.06mm BLACK OXIDE
N
1 HNT140700-1300 NUT M4.0xOD7.0xT3.0mm NICKEL
N
2 HOT002006-0003 CU-SPACER M3.0xP0.5xL20mm HEXAGO
ESC360 PART LIST
