JBL GTO5355 Service Manual

Part Number Qty Reference Designator
Description
MAIN PCB
1501-0300-02 terminal BTS3-24 1 CON3
1380-0211-00 temp switch 95℃ KSD-301 1
PL-L0002-000 terminal GND-3 1
3000-LGTO-01 Transformer φ37 6:12 L1=L2=0.8*10*6TS L3=L4=0.8*5*12TS 1 T1
2100-0074-02 cable
2PIN P=2.54MM 1007#26AWG L=100MM
(A2501TOP-2)
1
2100-0073-02 cable
2PIN P=2.54MM 1007#26AWG L=85MM
(A2501TOP-2)
1
PL-A0056-000 14.0x7.0x64.0 Alum. Bar with Insulated paper 2
PL-A0054-000 14.0x7.0x64.0 Alum. Bar with Insulated paper 4
PL-A0053-000 14.0x7.0x88.0 Alum. Bar with Insulated paper 2
PREAMP/INPUT PCB
Resistors
0702-1361-02 Resistor 1/8W 360Ω ±5% 7.5MM 4 R110D R110C R110B R110A
0702-1102-02 Resistor 1/8W 1KΩ ±5% 7.5MM 14
R407 R307 R117C R117A R116C R116A
R115C R115A R114C R114B R207 R114D
R114A R107
0702-1202-02 Resistor 1/8W 2KΩ ±5% 7.5MM 1 R132
0702-1472-02 Resistor 1/8W 4.7KΩ ±5% 7.5MM 6 R107D R107C R107A R107B R71 R72
0702-1562-02 Resistor 1/8W 5.6KΩ ±5% 7.5MM 4 R109D R109C R109B R109A
0702-1682-02 Resistor 1/8W 6.8KΩ ±5% 7.5MM 4 R106D R106B R106C R106A
0702-1103-02 Resistor 1/8W 10KΩ ±5% 7.5MM 33
R406 R405 R403 R402 R306 R305 R303 R302
R206 R205 R203 R202 R133 R108D R108C
R108B R108A R106 R105D R105C R105B
R105A R105 R104C R104B R103 R102D
R102C R102B R102A R102 R104D R104A
0702-1223-02 Resistor 1/8W 22KΩ ±5% 7.5MM 16
R101B R401 R301 R201 R111C R111B R101
R103A R103B R101C R101D R103C R103D
R101A R111D R111A
1204-5031-18 potentiometer
A50K R0971G2B W=5 KQ L=15MM T=7.5MM
M=1MM FREQ
2 VR102R VR102F
1204-2030-01 potentiometer B20K KQ L=15 ±10% ±3dB LEVEL 2 VR101R VR101F
Capacitors
06D212274001 Capacitor 220UF/25V ±20% 8*16 105℃ 5mm 4 C401 C301 C101 C201
06D212264102 Cap electro 22uF/25V ±20% 5*11 105℃ black 5MM 12
C403 C402 C303 C302 C203 C202 C103 C102
C101C C101A C101D C101B
06D431046000 porcelin Cap 0.1uF/50V ＋80%/-20% 5MM 4 C27A C26A C24 C21
06D232206000 porcelin Cap 22pF/50V ±20% 5MM 8 C406 C405 C306 C305 C206 C205 C106 C105
06D234707000 porcelin Cap 47pF/100V ±20% 5MM 4 C103D C103C C103B C103A
06D231006000 porcelin Cap 10pF/50V ±20% 5MM 8
C404 C304 C204 C104 C102D C102C C102A
C102B
06D328236200 Capacitor 823/50V ±5% 5MM 8
C105D C105C C105B C105A C104D C104C
C104B C104A
Semiconductors
03N1-1815-01 Transistor 2SC1815GR 150MA 60V 400MW NPN TO-92 1 Q1E
01JR-4558-01 Dual Op-amp NJM4558 11
U301 U201 U102D U102C U102B U102A
U101D U101C U101B U101A U101
2004-0014-00 LED Φ3.0MM blue with blue light 1 LED2
2000-0017-00 LED red with red light Φ3MM 2P 1 LED1
GTO5355
11
