JBL GTO7001 Service Manual

Part Number Qty Reference Designator
Description
MAIN PCB
06D231047000 Capacitor 0.1uF/100V ±20% 5 C65 C85 C86 C139 C140
06D374717400 Capacitor 470pF/100V ±5% 1 C124
06D224747701 Capacitor 474/100V ±20% 3 C135 C98 C152
06D321047200 Capacitor 104/100V ±5% 1 C122
06D341249000 Capacitor 124/63V ±5% MET 1 C46
06D341849400 Capacitor 184/63V ±5% MET 1 C2
06D322227200 Capacitor 222/100V ±5% 4 C97 C23 C24 CX10
06D344749400 Capacitor 474/63V ±5% MET 1 C1
06D346839001 Capacitor 683/63V ±5% MET 1 C47
06D22102C000 Capacitor 102/250V ±20% 1 CL102
06D342247400 Capacitor 224/100V ±5% MET 2 C102 C103
06D341039000 Capacitor 103/63V ±5% MET 2 C125 C126
06D2C3357700 Capacitor 3.3UF/100V ±20% 1 C105
06D2C335C700 Capacitor 3.3UF/250V ±20% 1 C96
06D212266010 CAP Electro 22uF/50V ±20% 5*11 105℃ 8 CX3 CX4 C3 C4 C7 C8 C31 C41
06D211064100 CAP Electro 10uF/25V ±20% 5*11 105℃ 1 C136
06D211074100 CAP Electro 100uF/25V ±20% 6.3*11 105℃ 1 C123
06D211073001 CAP Electro 100UF/16V ±20% 6*7 105℃ 3 C130 C131 C129
06D212264103 CAP Electro 220uF/25V ±20% 8*12 105℃ 2 C87 C88
06D214764102 CAP Electro 47uF/25V ±20% 5*11 105℃ 3 C49 C50 C35
06D214775101 CAP Electro 470UF/35V ±20% Ф8*20MM 105℃ 3 C127 C133 C134
06D2C1067001 Capacitor 10UF/100V ±20% 4 C67 C101 C106 C141
06D213387001 CAP Electro 3300UF/100V 35*30MM ±20% 4 C145 C146 C147 C148
06D213384000 CAP Electro 3300UF/25V 16*30MM ±20% 10502 4 C109 C110 C111 C112
06D202264000 CAP Electro 22UF/25V ±20% 5*11 105℃ 3 C119 cx1 cx2
Semiconductors
2202-1620-05 Diode MUR1620CTA KAD 16A/200V TO-220 2 D30 D31
2202-1602-05 Diode UF1602CT AKA 16/200V TO-220 2 D32 D33
04WY-51AV101 Diode SMD 5.1V DO-213AA 0.5W 2 DZ2 DZ3
04PT-4148-01 Diode SMD 1N4148 DO-213AA 11
D1 D43 D44 D46 D47 D51 D6 D9 D10
D11 D14
03N1-5551-04 Transistor SMD MMBT5551LT1 NPN SOT-23 11
Q13 Q1 Q2 Q3 Q4 Q5 Q6 Q7 Q8 Q37
Q38
03N1-2222-04 Transistor SMD BT2222 SOT-23 NPN 1 Q29
01JR-4560-08 Dual Op-amp SMD 4560 SOP-8 JRC 5 U1 U2 U3 U4 U5
04ZL-4004-03 Diode 1N4004 DO-41 1 D16
04ZL-6A10-00 Diode 6A10 1000V 1 D17
03D1-TP50-24 N-chan Mosfet TP50N20P TO-220 4 Q9 Q10 Q11 Q12
03D1-50N6-24 N-chan Mosfet HFP50N06 TO-220 8 Q21 Q22 Q23 Q24 Q25 Q26 Q27 Q28
01FA-7912-04 neg -12v Regulator KA7912 TO-220 FAIRCHILD 1 U14
01FA-7812-04 pos +12V Regulator KA7812E TO-220 FAIRCHILD 2 U13 U15
2004-0014-00 LED Φ3.0MM Blue 1 LED1
2000-0017-00 LED Φ3MM 2P Red 1 LED2
2601-0202-00 Optocoupler LCR-0202 1 LCR1
Miscellaneous
1601-253G-00 FUSE 25A/32V 3 F1
2901-224C-00 Relay YL-224-C DC12V 30A 1 RL1
1001-4000-10 Inductor 40UH 40A :ETD-49 φ0.1*80*14TS 1 L4
1001-1820-10 Inductor ф32 1.8MH L1=L2 ф1.0*12 4TS 38*22MM 1 L6
1001-3001-10 Inductor 35UH φ25 φ0.3*20*2Ts 1 L5
1413-0001-00 jack 6P4C RJ11 HPCB-3021-6P4C 1 JK1
1404-0020-04 RCA jack AV4-8.4-38 1 J1
1401-0001-03 Fuse holder 3PIN BXS3-09 1 for F1
GTO7001
9
