JBL GTO7001 Service Manual

Part Number Qty Reference Designator
Description
MAIN PCB
3000-7001-01 Transformer
ф47 4:20:6:7 F1=F2=ф1.0*8 4TS
S1=S2=ф1.0*6 20TS S3=S4=ф1.0*16TS
S5:S6:ф1.0*1 7TS
1L8
1380-0206-00 temperature switch 80℃ KSD301 1 SW2
1501-0300-02 Terminal BTS3-24 1 CN2
1501-0400-01 Terminal BTS4-23 1 CN3
1004-3000-10 Inductor 30UH φ12*φ5 2
1502-0209-00 jack PITCH 2.54mm 2PIN 1 CN1
2102-0159-02 line 2PIN UL1007 AWG 26 L=70MM 1 SW2
PL-A0051-000 14.0*7.0*30.0 Alum. Bar with Insulated paper 2
PL-A0054-000 14.0*7.0*64.0 Alum. Bar with Insulated paper 3
PL-A0055-000 14.0*7.0*45.0 Alum. Bar with Insulated paper 1
CONTROL PCB
Resistors
0701-2104-02 Resistor SMD 100KΩ 1/8W ±5% 0805 1 R64
0701-2103-02 Resistor SMD 10KΩ 1/8W ±5% 0805 4 R3 R33 R30 R31
0701-2100-02 Resistor SMD 10Ω 1/8W ±5% 0805 4 R117 R118 R193 R198
0701-2102-02 Resistor SMD 1KΩ 1/8W ±5% 0805 2 R55 R58
0701-2222-02 Resistor SMD 2.2KΩ 1/8W ±5% 0805 2 R105 R106
0701-2203-02 Resistor SMD R0805 20KΩ 1/8W ±5% 1 R2
0701-2472-02 Resistor SMD 4.7KΩ 1/8W ±5% 0805 5 R40 R41 R42 R43 R44
0701-2471-02 Resistor SMD 470Ω 1/8W ±5% 0805 1 R45
0701-2681-02 Resistor SMD 680Ω 1/8W ±5% 0805 2 R116 R199
0701-2152-02 Resistor SMD 1.5KΩ 1/8W ±5% 0805 1 R56
0701-2101-02 Resistor SMD 100Ω 1/8W ±5% 0805 3 R49 R191 R192
0701-2303-03 Resistor SMD 30K 1/8W ±1% 0805 1 R29
0701-2221-02 Resistor SMD 220Ω 1/8W ±5% 0805 1 R113
0701-2331-02 Resistor SMD 330Ω 1/8W ±5% 0805 1 R48
0701-2473-02 Resistor SMD 47KΩ 1/8W ±5% 0805 1 R57
Capacitors
06S121026000 Capacitor SMD 1000pF/50V 0805 X7R ±10% 1 C100
06S321016000 Capacitor SMD 100pF/50V 0805 NPO ±5% 2 C61 C62
06S121046000 Capacitor SMD 0.1uF/50V 0805 X7R ±10% 8 C57 C59 C60 C63 C75 C77 C91 C92
06S132253000 Capacitor SMD 2.2uF/16V 1206 X7R ±10% 2 C104 E1
06S123326000 Capacitor SMD 332/50V ±10% X7R 0805 1 C64
06D211076100 CAP Electro 100uF/50V ±20% 8*12 105℃ 2 C93 C94
06D344727400 Capacitor 472/100V ±5% MET 2 C55 C56
06D214764102 CAP Electro 47uF/25V ±20% 5*11 105℃ 1 C43
06D211074100 CAP Electro 100uF/25V ±20% 6.3*11 105℃ 1 C58
Semiconductors
0100-C081-08 Single Op-Amp TLC081 SOP-8 1 U8
01LM-M555-08 Timer SMD LM555 SOP-8 1 U7
0100-74AH-00 Inverter 74AHC1G04 SOT-235 1 U16
0100-2010-00 High/Low side Driver IR2010S SOL-16 1 U10
03P1-5401-04 Transistor SMD MMBT5401LT1 PNP SOT-23 1 Q30
01TC-WH04-00 Triple Inverter TC7WH04F 1 U9
04ZL-2512-00 Diode SMD MUR120 1A 2512 1 D8
01LM-M311-08 Single Comparator SMD LM311 SOP-8 1 U11
04PT-4148-01 Diode SMD 1N4148 DO-213AA 5 D2 D3 D4 D7 D49
04WY-51AV101 Diode SMD 5.1V DO-213AA 0.5W 1 DZ1
2601-4N35-00 Optocoupler 4N35 6 1 U17
GTO7001
10
