JBL GTO7001 Service Manual

Part Number Qty Reference Designator
Description
CONTROL PCB
Miscellaneous
1505-1009-04 jack PITCH 2.54mm 10PIN 2 CN6
PWM PCB
Resistors
0701-2104-02 Resistor SMD 100KΩ 1/8W ±5% 0805 1 R154
0701-2113-02 Resistor SMD 11KΩ 1/8W ±5% 0805 1 R171
0701-2183-02 Resistor SMD 18KΩ 1/8W ±5% 0805 1 R175
0701-2222-02 Resistor SMD 2.2KΩ 1/8W ±5% 0805 1 R132
0701-2472-02 Resistor SMD 4.7KΩ 1/8W ±5% 0805 1 R46
0701-2432-02 Resistor SMD 4.3KΩ 1/8W ±5% 0805 1 R102
0701-2103-02 Resistor SMD 10KΩ 1/8W ±5% 0805 2 R36 R34
0701-2123-02 Resistor SMD 12KΩ 1/8W ±5% 0805 2 R35 R149
0701-2102-02 Resistor SMD 1KΩ 1/8W ±5% 0805 2 R155 R156
0701-2202-02 Resistor SMD R0805 2KΩ 1/8W ±5% 1 R138
0701-2473-02 Resistor SMD 47KΩ 1/8W ±5% 0805 2 R19 R20
0701-2623-02 Resistor SMD 62KΩ 1/8W ±5% 0805 1 R12
Capacitors
06S121026000 Capacitor SMD 1000pF/50V 0805 X7R ±10% 1 C143
06S121046000 Capacitor SMD 0.1uF/50V 0805 X7R ±10% 9
C1 C79 C81 C82 C84 C117 C132 C80
C151
Semiconductors
04PT-4148-01 Diode SMD 1N4148 DO-213AA 10
D41 D40 D39 D38 D36 D5 D19D37 D15
D18
03N1-5551-04 Transistor SMD MMBT5551LT1 NPN SOT-23 1 Q33
03P1-5401-04 Transistor SMD MMBT5401LT1 PNP SOT-23 1 Q32
01TI-L494-09 PWM IC SMD TL494C SO-16 1 U18
03P1-1023-01 Transistor A1023 TO-92 PNP 2 Q19 Q20
03P1-B649-07 Transistor 2SB649A 1.5A 180V 20W PNP TO-126 1 Q17
Miscellaneous
1501-0509-04 jack PITCH 2.54mm 5PIN 1 CN7
1501-0409-02 jack PITCH 2.54mm 4PIN 1
1003-1010-08 Inductor SMD 100MH 100MHZ 4A 2 L1 L2
LED PCB
2100-0067-02 line 2PIN UL1007 AWG26 L=70mm t=5mm 2
2100-0068-02 line 2PIN UL1007 AWG26 L=210mm 1
2005-0009-00 LED LED 2*3*4mm、white 8
LED1 LED2 LED3 LED4 LED5 LED6
LED7 LED8
0701-3102-02 Resistor SMD 1KΩ 1/4W ±5% 1206 8 R1 R2 R3 R4 R5 R6 R7 R8
06S121046000 Capacitor SMD 0.1uF/50V 0805 X7R ±10% 1 C1
GTO7001
11
