two. Speaker Connections
Connection Tips
– +– +
– + – +
Speaker Outputs
RIGHT LEFT
RIGHT LEFT
Speakers and electronics terminals have corresponding (+) and
(–) terminals. It is important to connect both speakers identi-
cally: (+) on the speaker to (+) on the amplifier and (–) on the
speaker to (–) on the amplifier. Wiring “out of phase” results in
thin sound, weak bass and a poor stereo image.
– +– +
– +
– +
Speaker Outputs
RIGHT LEFT
RIGHT
LEFT
HLS610, HLS615, HLS620, HLS810, HLS820, HLS Center
HLS410
