PARTS LIST K2 S9800
K2 S9800/K2 S9800SE
Rev 1 5/07
Harman Consumer Group, Inc., 250 Crossways Park Drive, Woodbury, New York 11797
Technical Manual
K2 S9800/K2 S9800SE
ITEM NO. PART NO. DESCRIPTION QTY.
1. 337627-003 HF DRIVER HORN 1
2. 338154-001 FRONT BAFFLE 1
3. 337978-001 CROSSOVER NETWORK 1
4. 336308-001 15" WOOFER 1500AL 1
5. 337361-001 HF DRIVER 435BE 1
6. 336318-001 UHF DRIVER 045BE 1
7. 338067-002 FOOT, BASE 4
8. 336921-003 CABINET TOP 1
9. 337106-002 UHF DRIVER HORN 1
10. 337534-003 UHF DRIVER HOUSING 1
11. 337854-001 FRONT GRILLE 1
12. 335202-002 PORT TUBE, METAL 2
13. 335203-001 PORT TUBE, FOAM 2
14. 335339-003 PORT TUBE, PLASTIC, 1.57" 2
15. 333249-001 GRILLE CUP 4
16. 59266 DOWEL PIN (not used in later versions
) 8
17. 338073-001 15" WOOFER GASKET 1
18. 337514-001 HF HORN GASKET 1
19. 338166-001 UHF GASKET, TOP 1
20. 338165-001 UHF GASKET, BOTTOM 1
21. 337916-001 CURVED, CABINET PANEL 1
22. 338168-001 FOOT GASKET 4
23. 902201-016 SCREW, MS, FLPH, 10-32X1.0 BLK, WFR TO ENCL 8
24. 902301-024 SCREW, MS, BHXS, .25-20x1.50, BLK, HF DRVR TO HORN 3
25. 902301-022 SCREW, MS, BHXS, .25-20x1.38, BLK, TOP TO ENCL 6
26. 909904-004 SCREW, MS, BSH, 6-32X.25, SST, TWT HORN TO ANGLE BRKT/TOP 2
27. 900201-010 SCREW, MS, PPH, 8-32x.625", BLK, TWT HOUSING TO TOP 4
28. 910002-016 SCREW, MS, FLPH, .25-20, ZINC, FOOT TO BASE 4
29. 903401-012 SCREW, PB, PPH, #6x.75, BLK, NETWORK TO ENCL 6
30. 338078-001 SHIM 6
31. 338167-001 ANGLE BRACKET FOR UHF DRIVER 2
32. 74714 JBL LOGO 1
33. 338470-001 STAND-OFF, .5" 4
34. 332259-001 NYLON INSERT 6
35. 337183-001 WASHER, FLAT, .25x.5", ZINC, 6X-TOP/ENCL, 3X-DRVR HF/HORN 13
36. 338528-001 XOVER DAMPENING PAD 1
37. 47264 BOLT, HEX HD, .25-20x.75, ZINC, ENCL TO HORN 4
38. 338536-001 GASKET, WASHER, .312ODX.156ID 4
39. 338470-002 STAND-OFF, 2.3" 2
40. 909904-006 SCREW, MS, BSH, 6-32X.38, SST 2
41. 338067-003 FOOT, SLIDE 4
PACKING
42. 338313-001 OUTER CARTON 1
43. 338314-001 PAD, END, TOP 1
44. 338315-001 PAD, END, BOT 1
45. OWNER’S MANUAL Download from http://www.jbl.com
46. 338067-004 FOOT, SPIKE 4
47. 338067-005 FOOT, BASE, FLOOR 4
71880 WHEEL SPACER, BASE 4
71885 WHEEL SPACER, SCREW 4
