JBL M2 User Manual

9
English
The M2 is designed for use in cinema
applications with perforated projection
screens. The wide directivity and
relatively shallow depth of the M2
waveguide permit a range of speaker-
to-screen distances with little variation
in performance. Digital equalizers
in Crown power amplifiers and BSS
Soundweb London processors used in
the M2 System compensate for screen
loss, and restore neutral frequency
response in the listening space.
Additionally specialized equalization
curves can be applied such as the X
curve. EQ and tuning recommendations
can be found in the Downloads Section
at www.jblpro.com/M2.
Use with perforated projection screens

JBL M2 Specifications

General

Impedance	8 Ohms
Weight	56.7 kg (125 lb)
Crossover Frequency	800 Hz
Coverage Pattern	120° x 100°
Maximum Peak SPL	123dB
Woofer Size	15 in
Sensitivity	92 dB, 1W @ 1m
LF Driver	2216Nd
Tweeter Size	3 inches
