Rear and Height Configuration (MA9100HP) - It is possible to assign your Height amplifier channels to Top Front, Top
Middle or Top Rear for a Dolby Atmos speaker configuration.
In addition, the Height amplifier channels can be assigned to provide a stereo downmix of the Main zone to a secondary
location of the home, called Party mode. You can also assign these channels to bi-amp the front left/right channels.
MA9100HP amplifier assignments:
Labels
Fixed
Front
Center
Surround
Assignable
Rear Surround Top Front Top Middle
Height Top Front Top Middle Top Rear
Party Bi-Amp
Subwoofer – Configures the subwoofer outputs when a subwoofer is present. Both subwoofer outputs 1 & 2 are
enabled when set to “Present”. The same signal is sent to both subwoofer outputs.
Height Type - Configures the type of height speakers - ceiling mounted or Dolby-enabled.
Note: Dolby Atmos-enabled speakers direct sound upward and reflect off the ceiling to produce overhead sound.
