SPEAKER SETUP
The settings on this page define your speaker configuration and adjustment setting based on their performance and placement
in the room. These settings are applied to all audio inputs and are stored in memory and recalled each time the unit is
powered up.
Speaker Types - Define the types of loudspeakers you have connected in your configuration. Here you set the type of
speakers that you have connected to your Receiver.
Capable of full frequency range reproduction.
Not capable of full frequency range reproduction at the low frequency end.
Speaker not present in your configuration.
Note: It is not possible to set all speakers to Small unless there is a subwoofer in your speaker
configuration. If you do not have a subwoofer, you will be forced to set your front speakers to Large.
Rear Configuration (MA7100HP) - It is possible to assign your rear surround amplifier channels to Top Front or Top
Middle for a Dolby Atmos speaker configuration.
In addition, the rear surround amplifier channels can be assigned to provide a stereo downmix of the Main zone to a
secondary location of the home, called Party mode. You can also assign these channels to bi-amp the front left/right
channels.
MA7100HP amplifier assignments:
Fixed
Front
Center
Surround
Assignable Rear Surround Top Front Top Middle Party Bi-Amp
