Operation
Table 1. JBL MPA-Series AC Power Consumption vs Load Impedance With 110, 115 and 120V Mains
2 CH Load Max Power AC Current AC Current AC Current AC Current
Model (Ohms) (Midband) Full Power 1/3 Power 1/8 Power Idle
8+8 740 x 2 23.0 A 10.2A 5.4 A
MPA1100 4+4 1000 x 2 38.0 A 16.0 A 7.8 A 0.9 A
2+2 1300 x 2 54.0 A 23.0 A 11.4 A
8+8 480 x 2 18.0 A 9.6A 4.6 A
MPA750 4+4 700 x 2 29.0 A 14.4 A 6.4 A 0.7 A
2+2 950 x 2 38.0 A 21.0 A 10.0 A
8+8 400 x 2 15.2 A 8.4 A 3.4 A
MPA600 4+4 550 x 2 22.0 A 13.5 A 5.4 A 0.5 A
2+2 675 x 2 32.0 A 15.2 A 8.0 A
8+8 275 x 2 11.2 A 6.6 A 2.6 A
MPA400 4+4 400 x 2 16.0 A 9.6 A 4.6 A 0.4 A
2+2 525 x 2 22.0 A 13.2 A 5.4 A
8+8 180 x 2 7.6 A 5.4 A 3.6 A
MPA275 4+4 275 x 2 12.0 A 7.2 A 5.2 A 0.4 A
2+2 425 x 2 18.2 A 11.2 A 7.0 A
Operation With 110 VAC, 60 Hz Power Mains
8+8 770 x 2 24.0 A 10.4 A 5.6 A
MPA1100 4+4 1100 x 2 39.0 A 16.6 A 8.0 A 1.0 A
2+2 1400 x 2 56.0 A 23.4 A 11.8 A
8+8 510 x 2 18.6 A 9.8A 4.8 A
MPA750 4+4 760 x 2 30.0 A 14.8 A 6.8 A 0.8 A
2+2 1000 x 2 39.4 A 21.4 A 10.6 A
8+8 425 x 2 13.6 A 8.6 A 3.6 A
MPA600 4+4 610 x 2 23.0 A 13.4 A 5.6 A 0.6 A
2+2 750 x 2 33.0 A 15.6 A 8.6 A
8+8 290 x 2 11.6 A 6.8 A 2.8 A
MPA400 4+4 425 x 2 17.0 A 9.8 A 4.8 A 0.4 A
2+2 575 x 2 23.0 A 13.6 A 5.6 A.
8+8 190 x 2 7.8 A 5.6 A 3.8 A
MPA275 4+4 300 x 2 13.6 A 7.6 A 5.6 A 0.4 A
2+2 450 x 2 19.2 A 11.6 A 7.4 A
Operation With 115 VAC, 60 Hz Power Mains
8+8 800 x 2 25.0 A 10.8 A 5.8 A
MPA1100 4+4 1200 x 2 40.0 A 17.0 A 8.4 A 1.0 A
2+2 1500 x 2 58.0 A 24.0 A 12.0 A
8+8 550 x 2 19.0 A 10.0 A 5.0 A
MPA750 4+4 825 x 2 31.0 A 15.2 A 7.4 A 0.8 A
2+2 1100 x 2 41.0 A 22.0 A 11.0 A
8+8 450 x 2 16.0 A 9.0 A 4.0 A
MPA600 4+4 675 x 2 24.0 A 14.0 A 6.0 A 0.6 A
2+2 825 x 2 34.0 A 16.0 A 9.0 A
8+8 300 x 2 12.0 A 7.0 A 3.0 A
MPA400 4+4 450 x 2 18.0 A 10.0 A 5.0 A 0.4 A
2+2 650 x 2 24.0 A 14.0 A 6.0 A.
8+8 200 x 2 8.0 A 6.0 A 4.0 A
MPA275 4+4 325 x 2 13.0 A 8.0 A 6.0 A 0.4 A
2+2 500 x 2 20.0 A 12.0 A 8.0 A
Operation With 120 VAC, 60 Hz Power Mains
