JBL MR-4.2 - Operating the CD Player; Installation; Installation Precautions and Adjustment

1. Select the RADIO / CD / AUX by pressing the "MODE" button (4) in sequence.
2. Track tuning (9)
Search the track on the DISC with & buttons. If you press or button
continuously, the track goes fast forward or rewind.
3. Play / pause (10)
Push to pause and push again to resume play.
4. Intro Scan (11)
Press this button to hear the first 10 seconds of each track on the disc.
Press this button again to restore the player to its normal play mode.
5. Repeat Play button (12)
While playing a desired track, press the RPT button to play the track repeatedly.
Press the RPT button again to return to normal play mode.
6. Random play button (13)
Press the RDM button to play all tracks on a CD in random sequence.
Press the RDM button again to return the player to normal mode.
Operating the CD Player
Installation
12
5
1. Precautions
Choose the mounting location carefully so that the unit will not interfere with the
normal driving functions of the boat.
Avoid installing the unit where it would be subject to high temperature (such as from
direct sunlight or hot air) or where it would be subject to dust, dirt or excessive
vibration. Use only the supplied mounting hardware for a safe and secure installation.
Be sure to remove the front panel before installing the unit.
2. Mounting angle adjustment
Adjust the mounting angle to less than 20 degrees from the horizontal position.
3. Mounting example
1 2
4
Release Key
Half Cabinet
Tap
Bend these claws, if necessary.
3
<< Installation in the cabinet >>
Note Keep the release key in a safe place as you may need it in future to remove
the unit from the boat.
145x210mm
3
2
7
4
8
18
16
10
11
12
13
14
15
6
17
1
5
9
MARINEMARINE
PWR
MOD
MR - 4.2
4CHx45Watts
2 INT
3 RPT
5
6
SCN
BD/LD
T
/F
MUTE
A.
P
S
REL
1
IEQ
COMPACT DISC PLAYER
DETACHABLE SYSTEM
4 RDM
