JBL PARTYBOX Encore Essential User Manual

88
4. PLACEMENT
Caution:
– Do not sit on the speaker to avoid possible damages.
Place the speaker on a at, stable surface and ensure that the
rubber feet side is down.
5. POWER ON
Cautions:
– Use the provided power cords only.
– You can use either AC power or the built-in battery as power
supply to the speaker.
1
2
OFF
ON
100%50%20%
1. Connect AC power.
• To use the built-in battery, disconnect AC power after
charging the speaker.
2. Press to power on.
Tips:
– Fully charge the speaker before rst-time use to prolong the
lifespan of the built-in battery.
– When the speaker is on, you can check the battery level by
pressing any button on the speaker.
– The speaker switches to standby mode automatically after
20 minutes of inactivity. You can press on the speaker to switch
to normal operation.

JBL PARTYBOX Encore Essential Specifications

General

Tweeter	Yes
Woofer diameter	133 mm
Tweeter diameter	45 mm
Number of speakers	1
Number of tweeter drivers	2
Woofer diameter (imperial)	5.25 \
Tweeter diameter (imperial)	1.75 \
Frequency range	50 - 20000 Hz
RMS rated power	100 W
Signal-to-Noise Ratio (SNR)	80 dB
Wi-Fi	-
Bluetooth version	5.1
Bluetooth profiles	A2DP, AVRCP
Connectivity technology	Wired & Wireless
Bluetooth transmitter modulation	8DPSK, DQPSK, GFSK
Product type	Mono portable speaker
Product color	Black
International Protection (IP) code	IPX4
Certification	CE
Recommended usage	Universal
Card reader integrated	No
Audio formats supported	MP3, WAV, WMA
Cables included	AC
Battery type	Built-in battery
Battery voltage	3.7 V
Battery capacity	17.76 Wh
Battery life (max)	6 h
AC adapter frequency	50/60 Hz
Battery recharge time	3.5 h
AC adapter input voltage	100 - 240 V
Package depth	326 mm
Package width	472 mm
Package height	354 mm
Package weight	7270 g

Weight and Dimensions

Depth	293 mm
Width	276 mm
Height	327 mm
Weight	5900 g
