PRX915XLF SPECIFICATIONS
TECHNICAL SPECIFICATIONS
System Type 15IN Powered Subwoofer
Woofer Model 915SG
Woofer Size 15"
Woofer Magnet Ferrite
Woofer Voice Coil 3"
Transducer Impedence Rated: woofer: 4Ω
Max SPL 131dB @1m/2Pi
Freq Range -10 36Hz - 98Hz (2Pi)
Freq Range -3 40Hz - 87Hz (2Pi)
Hor Dispersion Omni
Vert Dispersion Omni
Crossover Frequency 80Hz, 100Hz, 120Hz Selectable
Power Rating 2000W peak
AC Power Input 100-230Vrms 50-60Hz
Cooling Natural convection, No fan
LED Indicators Limit, 2x SSM Input
Input Impedence 100KΩ Balanced
Input Gain -100 to +12dB
I/O x2 Combo inputs
x2 XLR pass through outputs
Cabinet 18mm Plywood + Duraflex
Grille Powder coated Steel , T=1.5mm
Suspension/Mount Pole mount on top surface
Handles Side Handle x2
Net Weight 28.6kg
Gross Weight 33.6kg
Product Dims 549 x 480 x 580 (H x W x D mm)
Shipping Dims 594 x 692 x 600 (H x W x D mm)
