JBL PRX 918XLF User Manual

21
PRX918XLF SPECIFICATIONS
TECHNICAL SPECIFICATIONS
System Type 18IN Powered Subwoofer
Woofer Model 918SG
Woofer Size 18"
Woofer Magnet Ferrite
Woofer Voice Coil 4"
Transducer Impedence Rated: woofer: 4Ω
Max SPL 134dB @1m/2Pi
Freq Range -10 30Hz - 110Hz (2Pi)
Freq Range -3 35Hz - 92Hz (2Pi)
Hor Dispersion Omni
Vert Dispersion Omni
Crossover Frequency 80Hz, 100Hz, 120Hz Selectable
Power Rating 2000W Peak
AC Power Input 100-230Vrms 50-60Hz
Cooling Natural convection, No fan
LED Indicators Limit, 2x SSM Input
Input Impedence 100KΩ Balanced
Input Gain -100 to +12dB
I/O x2 Combo inputs
x2 XLR pass through outputs
Cabinet 18mm Plywood + Duraflex
Grille Powder coated Steel , T=1.5mm
Suspension/Mount Pole mount on top surface
Handles Side Handle x2
Net Weight 40.7kg
Gross Weight 47.5kg
Product Dims 693 x 591 x 654 (H x W x D mm)
Shipping Dims 740 x 768 x 705 (H x W x D mm)
