JBL radial micro User Manual

7
Symptom Possible Problem Solution Note
Remote
The remote’s battery power
may be low.
Replace battery.
Redock the iPod. If problem
persists, reset the iPod.
Pod does not respond to remote
commands.
Interference from surrounding
devices.
JBL Radial Micro is in “off”
mode.
Move your JBL Radial Micro to
another location.
Ensure JBL Radial Micro is
plugged into wall outlet and unit
is turned on.
The remote range is up to
20 feet.
Remote only operates at close
range.
The remote battery power may
be low.
Replace battery.
Move the source unit closer to
the remote.
Possible sources of interference
include plasma displays,
dimmer-controlled lighting,
bright sunlight, and reective
surfaces such as mirrors or
blank walls.
Manufacturer: Harman Kardon Multimedia
Model Name: JBL Radial Micro
Available in: White or Black
Requirements: Main connection – iPod docking connector; Auxiliary connection – 1/8
(3.5mm) mini stereo jack
Drivers: Four OdysseyTM transducers
Power: 2 x 10 Watts @ 10% THD
Frequency Response: 60Hz – 20KHz
Dimensions: Width: 8 (203mm)
Height: 8 (203mm)
Depth: 3.5 (89mm)
Weight: 1.1 lb (0.5kg)
Input Impedance: >5k Ohms
Signal-to-Noise Ratio: >85dB
Power Supply: Input: 100 – 240V AC, 50Hz/60Hz 0.5A
Output: 12V DC, 1.25A
JBL 10-Button Remote
Transmission: IR
Frequency: 38kHz
Operating Range: 20 feet
Battery Type: CR2032 3V
Dimensions: Width: 1.29 (33mm)
Height: 3.38 (86mm)
Depth: 0.23 (6mm)
Weight (including battery): 1.2 oz
Technical Specications
This device is susceptible to interference from other appliances plugged into nearby outlets. If you experience interference,
JBL recommends moving the device or the other appliance to a different outlet.

JBL radial micro Specifications

General

Impedance	5000 Ω
Frequency range	60 - 20000 Hz
RMS rated power	20 W
Signal-to-Noise Ratio (SNR)	85 dB
Magnet type	Neodymium
Product color	White
AC input voltage	230 V
Dimensions (WxDxH)	200 x 90 x 200 mm

Weight and Dimensions

Weight	500 g
