JBL SCS 138-178 - Component Parts List; PCBs, ICs, and Resistors

106SUB138E 106SUB138E
PART NO. DESCRIPTION QTY REFERENCE
1 101OSUB138C PCB AMP ASS'Y 1
2 101ASUB138C AI PCB AMP ASS'Y 1
3 104sub138c01 PCB 1
4 11016103j26 Resistor 10K 1/6W ±5% CF 1 R303
5 11016273j26 Resistor27K 1/6W ±5% CF 1 R304
6 11016472j26 Resistor 4.7K 1/6W ±5% CF 2 R301,2
7 115h203b205 Variable Resistor B20K 1 VR302
8 115h503a202 Variable Resistor A50K 1 VR301
9 180sms50126 SLIDE SW MS50126 1 SW301
10 19006m4558d I.C. OPA 4558D 1 U301
11 101OSUB138E PCB ASS'Y AMP 1
12 101ASUB138E AI PCB ASS'Y AMP OF SUB138 1
13 104sub135e00 PCB OF SUB135CE 1
14 11014122j26 Resistor 1.2K 1/4W ±5% CF 1 R265
15 11014472j26 Resistor 4.7K 1/4W ±5% CF 2 R201,2
16 11014560j26 Resistor 56 1/4W ±5% CF 1 R117
17 11016101j26 Resistor 100 1/6W ±5% CF 4 R120,213,4,5
18 11016102j26 Resistor1K 1/6W ±5% CF 3 R124,66,254
19 11016103j26 Resistor 10K 1/6W ±5% CF 17 R133,4,209,12,6,7,20,1,2,5,8,9,30,2,5,40,60
20 11016104j26 Resistor100K 1/6W ±5% CF 3 R231,163,4
21 11016105j26 Resistor1M 1/6W ±5% CF 2 R143,259
22 11016123j26 Resistor 12K 1/6W ±5% CF 3 R135,9,65
23 11016124j26 Resistor 120K 1/6W ±5% CF 1 R233
