Component Video Performance
Component Video Performance (continued)
Other
• <3dB
• >150MHz
Insertion Loss
Bandwidth
•1 power on/off and 1 programmable connector on
detachable screw terminals (+12 VDC, 0.5 amps each)
Trigger Outputs
•2 9-pin D-sub connectors
• 90-250 VAC, 50-60Hz, 60W (universal line input),
detachable power cord
• Hand-held, backlit infrared remote control unit
•Requires 2 AA batteries (Alkaline batteries recommended)
• Height (with feet): 5.04 inches (128mm)
•Width: 17.3 inches (440mm)
• Depth: 14.85 inches (377mm)
•Weight: 24lbs (10.7kg)
• Brackets are provided for installation in a standard 19"
equipment rack (3 rack units required).
• Operating Temperature: 0° to 35°C (32° to 95°F)
• Storage Temperature: -30° to 75°C (-22° to 167°F)
• Relative Humidity: 95% maximum without condensation
RS-232 Serial Input/
Output
Power Requirements
SDP-5
Dimensions & Weight
Rack Mounting
Environment
Remote Control
Composite & S-video Performance
Video Input & Output Connectors
Appendix
SDP-5
A-3
Specifications are subject to change without notice.
•5 composite (RCA), 5 S-video, and 3 component
video (RCA)
•2 composite (RCA, 1 monitor and 1 Zone2), 2 S-video
(1 monitor and 1 Zone2), and 1 component (RCA)
Video Inputs
Video Outputs
• NTSC, PAL, and SECAM
• Active
• 1.0V peak-to-peak
Compatibility
Switching
Output Level
•75Ω
• >40dB
• <0.5%
• <0.5°
• >25MHz
• <0.3%
•±0.15dB
• >65dB
Impedance
Input Return Loss
Differential Gain
Differential Phase
Bandwidth
K Factor
Gain
Signal-to-Noise Ratio
• 10Hz to 10MHz + 0.1/-0.3dBFrequency Response
• 3-channel (Y, Pr, Pb), format-independent
• Passive
•75Ω
Compatibility
Switching
Impedance
