SETUP
SDP-5
3-45
SUB LIMITER ON, OFF
Limits output signals for the Main Zone audio output connector
labeled Subwoofer, as well as other Main Zone audio output
connectors to which low-frequency signals are redirected. When set
to ON, the SDP-5 restricts output signals to the level specified in
the BASS PEAK LIMITER menu SUB LIMIT ADJ parameter. When set
to OFF, the SDP-5 does not restrict output levels, regardless of the
SUB LIMIT ADJ parameter setting.
SUB LIMITER
75 to 120dB
SUB LIMIT ADJ 75 to 120dB
Specifies the output level restriction placed on the Main Zone
audio output connector labeled Subwoofer, as well as other Main
Zone audio output connectors to which low-frequency signals are
redirected. This restriction is applied when the BASS PEAK LIMITER
menu SUB LIMITER parameter is set to ON. When the SUB LIMIT
ADJ parameter is selected, it is automatically set to 75dB.
SUB LIMIT ADJ
