Basic Operation
SDP-5
2-7
9. Video Input Connectors
Provide video input in the Main Zone and Zone 2. Five
composite video connectors labeled Video 1 to 5, five S-video
connectors labeled S-Video 1 to 5, and three component video
connectors labeled 1 to 3 are available. The component video
connectors are not available for Zone 2.
10.Main Zone Video Output Connectors
Provide video output in the Main Zone. One composite video
connector, one S-video connector, and one component video
connector are available.
11.Zone 2 Video Output Connectors
Provide video output in Zone 2. One composite video
connector and one S-video connector are available.
Alternatively, these connectors can be used to connect a video
recording device.
Note:
Composite video output connectors are available
when a composite or S-video source is present.
S-video output connectors are available when an
S-video source is present.
Component video output connectors are available
when a component video source is present.
12.IR IN Connector
Accepts input of IR signals from infrared distribution
equipment. One 3.5mm jack that accepts a stereo plug (Tip/
Ring connection) or mono plug (Tip/Sleeve connection) is
available.
13.RS-232 Connectors
The RS-232 connector labeled 1 provides serial control. It is
capable of performing configuration downloads and flash
memory software upgrades. The RS-232 connector labeled 2 is
capable of supporting future developments.
14.Trigger Output Connectors
Provide 12V DC output to control connected components.
Two trigger output connectors are available on a 5-pin DIN
connector. The connector labeled PWR – the power trigger
output connector – is not configurable. It is activated when the
SDP-5 is activated, and deactivated when the SDP-5 is
deactivated. The trigger output connector labeled 1 can be
configured for remote or program operation. Refer to page
3-54 for more information.
Note:
The default trigger configuration shown on page
3-55 includes settings designed for use in JBL
Synthesis systems with switching transducers for
listening modes.
15.Removable Access Panels
Accommodate connectors for emerging technologies.
GROUND
TRIGGER 1
POWER TRIGGER
TRIGGER 2
GROUND
