SETUP
SDP-5
3-19
DIGITAL ANALOG AUTO
The SDP-5 automatically sets the INPUT
SELECT parameter to DIGITAL when the
ANALOG IN parameter is set to NONE.
• The SDP-5 sends the assigned digital
audio input connector to the Main Zone
audio output connectors. The SDP-5
ignores the assigned analog audio input
connector.
• The digital audio input connectors are
compatible with PCM (44.1, 48, 88.2,
and 96kHz), Dolby Digital, and dts(-ES)
sources. If an incompatible digital audio
source (i.e. MPEG or MP3) is present, the
SDP-5 automatically selects the assigned
analog audio input connector.
• The DIGITAL IN parameter (3-7) can be
used to assign a digital audio input
connector for the selected input.
The SDP-5 automatically sets the INPUT
SELECT parameter to ANALOG when the
DIGITAL IN parameter is set to NONE.
• The SDP-5 sends the assigned analog
audio input connector to the Main Zone
audio output connectors. The SDP-5
ignores the assigned digital audio input
connector.
• The ANALOG IN parameter (3-8) can be
used to assign an analog audio input
connector for the selected input.
The SDP-5 automatically sets the INPUT
SELECT parameter to AUTO when both digital
and analog audio input connectors are
assigned.
• The SDP-5 toggles between sending the
assigned digital and analog audio input
connectors to the Main Zone audio output
connectors based on the input source that
is present. For example:
– When a 2-channel PCM, Dolby Digital,
or dts(-ES) source is present, the SDP-5
automatically selects the assigned
digital audio input connector.
– When an SACD source is present, the
SDP-5 automatically selects the
assigned analog audio input
connector.
• The AUTO setting is recommended for
components that generate both digital
and analog signals, such as DVD/SACD
players.
INPUT SELECT Parameter Settings
The table below describes INPUT SELECT parameter settings.
. . . MAIN ADVANCED continues on page 3-20
