SETUP
SDP-5
3-43
SIDE LEFT & RIGHT -18.0 to +12.0dB
Set the output levels for the speakers connected to the Main Zone
audio output connectors labeled Side L/R.
REAR LEFT & RIGHT -18.0 to +12.0dB
Set the output levels for the speakers connected to the Main Zone
audio output connectors labeled Rear L/R.
SUBWOOFER -18.0 to +12.0dB
Sets the output level for the subwoofer connected to the Main
Zone audio output connector labeled Subwoofer.
SUBWOOFER
(TEST)
LEVELS CALIBRATION
SPEAKERS
SETUP
REAR RIGHTORREAR LEFT
(TEST)
LEVELS CALIBRATION
SPEAKERS
SETUP
SIDE RIGHTORSIDE LEFT
(TEST)
LEVELS CALIBRATION
SPEAKERS
SETUP
