5 ST. & (1) 5.1 ANLG (continued from page 3-45)
When the analog audio input connectors are configured as one
5.1-channel and five stereo connectors:
•Two-channel sources that were assigned to the stereo
connectors labeled 6, 7, and 8 are reassigned to the
5.1-channel connector labeled 6, 7, and 8. The 5.1-channel
connectors should only be used with 5.1-channel analog
sources such as DVD-As and SACDs.
2 ST. & (2) 5.1 ANLG
Configures the analog audio input connectors as two stereo and
two 5.1-channel connectors.
When the analog audio input connectors are configured as two
stereo and two 5.1-channel connectors:
• The connectors labeled 1 and 2 are configured as stereo
connectors.
• The connectors labeled 3, 4, and 5 are configured as a 5.1-
channel connector, and the connectors labeled 6, 7, and 8 are
configured as a 5.1-channel connector. These connectors are
sent to the Main Zone audio output connectors as indicated in
the table at the bottom of this column.
•Two-channel sources that were assigned to the stereo
connectors labeled 3, 4, and 5 are reassigned to the
5.1-channel connector labeled 3, 4, and 5. Two-channel
sources that were assigned to the stereo connectors labeled 6,
7, and 8 are reassigned to the 5.1-channel connector labeled
2 ST. & (2) 5.1 ANLG
SETUP
6, 7, and 8. The 5.1-channel connectors should only be used
with 5.1-channel analog sources such as DVD-As and SACDs.
The 5.1-channel analog audio input connectors are sent to the
Main Zone analog audio output connectors as shown in the
table below.
Input Connector Output Connector
(L) Front L
(R) Front R
(C) Center
(SUB) Subwoofer
(LS) Side L and Rear L
(RS) Side R and Rear R
